Crown Round

Die cast Aluminum frame with extruded Aluminum heat sink
High energy saving Vis a Vis Conventional Lighting-60% compared to CFL /Halogen Luminaires
Isolated constant current driver
More than 85% driver efficiency
Wide operating voltage 100 - 285Vac
Color Rendering Index (CRI) > 80
Working ambient temperature -20°C to + 45°C
Rated Life 50,000Hrs (Ta= 30°C @ L70)
High intensity of illumination with > 60°beam angle
Uniform diffuse & excellent glare control
Instant start without flash & humming
Electric wave & radio interference free
Without mercury,UV & IR radiation
IP 20 Ingress Protection

Product ID / Ordering Code	Product Description	Wattage(W)	Nominal Voltage(V)	CCT (K)	Lumen (lm)	Current (A)
VL/DNL-505-LED00365	Crown Rnd LED Spot light 03/ CW	3	230	0.026	6500	270
VL/DNL-505-LED00465	Crown Rnd LED Spot light 04/ CW	4	230	0.034	6500	360
VL/DNL-505-LED00565	Crown Rnd Spot light 05/ CW	5	230	0.042	6500	450
VL/DNL-505-LED00765	Crown Rnd LED Spot light 07/ CW	7	230	0.060	6500	630
VL/DNL-505-LED00965	Crown Rnd LED Spot light 09/ CW	9	230	0.072	6500	810
VL/DNL-505-LED01265	Crown Rnd LED Spot light 12/ CW	12	230	0.080	6500	1080
VL/DNL-505-LED01565	Crown Rnd LED Spot light 15/ CW	15	230	0.068	6500	1350
VL/DNL-505-LED02565	Crown Rnd Spot light 25/ CW	25	230	0.114	6500	2200
