Specifications & Features
- Die cast Aluminum (LM -6) housing with toughened glass cover
- Modular design with multiple LEDs
- 50% energy saving Vis a Vis Conventional HID Street light
- Over load, over voltage & short circuit protection
- Isolated constant current driver with PF > 95%
- More than 85% driver efficiency with < 10% Current THD
- Equipped with 10KV Surge suppression Protection
- Wide operating voltage 100 - 285V
- Color Rendering Index (CRI) > 80
- Working ambient temperature -25°C to + 50°C
- Rated Life 50,000Hrs (Ta= 30°C @ L70)
- High intensity of illumination with 120°view angle
- Uniform diffuse & excellent glare control
- Flicker free instant start electronic operation
- Optional secondary lens used for asymmetric wide distribution
- Electric wave & radio interference free
- Without mercury,UV & IR radiation
- Class I Electric Strength
- IP 65 / 66 Ingress Protection
- Side entry mounting suitable for Pole dia max 60mm
- Power supply should be disconnected before service
