Integral Well Glass Luminaires
Integral Well Glass Luminaires
Specifications & Features
- Pressure die cast aluminium corrosion resistant housing with gasket, heat resistant glass dome & M.S Powder coated wire guard ,
Copper wound ballast, PF correction capacitor, Electronic ignitor.
- Prewired upto terminal block
- Optional white powder coated external reflector
- Epoxy Powder coated painting
- E27 Porcelain Lamp holder base
- Earthing terminal
- IP 65 protection
- Power plant
- Steel plant
- Fertilizer plant
- Refineries
- Cable conveyor galleries
- Electrochemically brightened and high purity anodised aluminium reflector for efficient light distribution
| Part No |
Lamp Type |
Lamp Qty |
Wattage |
Nominal Rated Voltage |
A |
B |
| VL/WGB-50W |
MH |
1 |
50 |
220 / 240 |
350 |
200 |
| VL/WGB-70W |
MH / SV |
1 |
70 |
220 / 240 |
350 |
200 |
