I-Line T8

crompton make led fittings suppliers india

Specifications & Features

  • Extruded Aluminum batten with highly efficient PC Opal Diffuser.
  • High energy saving Vis a Vis Traditional fluorescent Tube - 50% compared to T8 or,T12 FTL and 35% to T5 FTL.
  • Direct power supply port with feasibility for series connection
  • Over load, over voltage, short circuit and reverse polarity protection
  • Integrated constant current driver with PF > 95%
  • More than 85% driver efficiency with < 20% Current THD
  • Equipped with 2.5KV Surge Protection
  • Wide operating voltage 100 - 277Vac
  • Color Rendering Index (CRI) > 80
  • Working ambient temperature -20°C to + 45°C
  • Rated Life 50,000Hrs (Ta= 30°C @ L70)
  • High intensity of illumination with 120°beam angle
  • Uniform diffuse & excellent glare control
  • Instant start without flash & humming
  • Electric wave & radio interference free
  • Without mercury,UV & IR radiation

  • Hotels
  • Institutions
  • Hospitality
  • Residential Lighting
  • Departmental Stores
  • High Ceiling Lighting
  • Factories

  • Mounted with wall mounting bracket
  • Power Supply should be disconnected before service

Technical & Ordering Information Download Datasheet

Product ID / Ordering Code Product Description Wattage(W) Nominal Voltage(V) Mains Current(A) CCT (K) Lumen (lm)
VL/ITL-300-LED001065 I-Line Integrated T8 LED batten 10/CW L600 10 230 0.045 6500 900
VL/ITL-300-LED001865 I-Line Intergated T8 LED batten 18/CW L1200 18 230 0.082 6500 1650
VL/ITL-300-LED002065 I-Line Integrated T8 LED batten 20/CW L1200 20 230 0.090 6500 1800
VL/ITL-300-LED002465 I-Line Integrated T8 LED batten 24/CW L1200 24 230 0.110 6500 2160

LED Batten / Luminaires
