Specifications & Features
- Extruded Aluminum batten with highly efficient PC Opal Diffuser.
- High energy saving Vis a Vis Traditional fluorescent Tube-70% compared to standard 2ft & 4ft T8 or,T12 FTL.
- Detected range of 5 - 8mtr with 120 Deg angle.
- Dim to 10% rated power within Interval time < 3 Min thr PIR Sensor
- Direct power supply port with feasibility for series connection
- Over load, over voltage, short circuit and reverse polarity protection
- More than 85% driver efficiency with < 20% Current THD
- Equipped with 2.5KV Surge Protection
- Wide operating voltage 100 - 277Vac
- Color Rendering Index (CRI) > 80
- Working ambient temperature -20°C to + 45°C
- Rated Life 50,000Hrs (Ta= 30°C @ L70)
- High intensity of illumination with 120°beam angle
- Uniform diffuse & excellent glare control
- Instant start without flash & humming
- Electric wave & radio interference free
- Without mercury,UV & IR radiation
- IP 20 Ingress Protection
- Offices
- Institutions
- Factories
- Warehouse
- Parking
- Corridors
- Commercial Centre
- Mounted with wall mounting bracket
- Power Supply should be disconnected before service
