Polar

led luminaires suppliers in tamilnadu

Specifications & Features

  • High grade CRCA pre coated frame with highly efficient Polychromatic dust resistant anti-static diffuser.
  • High energy saving vs Traditional fluorescent-60% compare to 2x36W PLL & 40% compare to 4x14W TL5
  • Constant current driver with > 95% power factor
  • More than 85% driver efficiency with < 15% current THD
  • Wide operating voltage 100 - 277Vac
  • Color Rendering Index (CRI) > 80
  • Working ambient temperature -20°C to + 45°C
  • Rated Life 35,000Hrs (Ta= 35°C @ L70)
  • High intensity of illumination with 115°beam angle
  • Uniform diffuse & excellent glare control
  • Instant start without flash & humming
  • Electric wave & radio interference resistant
  • Free of Mercury,UV & IR radiation
  • IP 20 Ingress Protection

  • Hotels
  • Conference / Meeting rooms
  • Offices
  • Commercial Purposes
  • Institutional Buildings
  • Educational Institute
  • Hospitals

  • Feasible for Surface,Recess & Suspension mounting
  • Suitable for Grid ceiling
  • Surface, POP & Gypsum Ceiling mounting using additional mounting clamps
  • Power supply should be disconnected before service

Technical & Ordering Information Download Datasheet

Product ID / Ordering Code Product Description Wattage(W) Nominal Voltage(V) CCT (K) Lumen (lm) Current (A)
VL/PNL-310-LED03230 Polar LED Panel 32/ WW L600 32 230 3000 2800 0.15
VL/PNL-310-LED03240 Polar LED Panel 32/ NW L600 32 230 4000 3100 0.15
VL/PNL-310-LED03265 Polar LED Panel 32/ CW L600 32 230 6500 3100 0.15

Panel Light
