Venus COB

Venus COB

led flood light suppliers in chennai

Specifications & Features

  • High pressure die cast Aluminum housing
  • Electrostatic spray Reflector
  • Highly efficient optical grade Polymer acrylic lenses
  • 60% energy saving Vis a Vis Conventional HID Bay light
  • Over load, over voltage & short circuit protection
  • Isolated constant current driver with PF > 95%
  • More than 85% driver efficiency with THDi < 10%
  • Equipped with 10KV Surge suppression Protection
  • Wide operating voltage 100 - 285V
  • Color Rendering Index (CRI) > 70
  • Working ambient temperature -20°C to + 50°C
  • Rated Life 50,000Hrs (Ta= 30°C @ L70)
  • High intensity of illumination with 120°view angle
  • Secondary lens and reflector provides desired light distribution
  • Flicker free instant start electronic operation
  • Electric wave & radio interference free
  • Without mercury, UV & IR radiation
  • IP 54 /65 Ingress Protection

  • Factory
  • Warehouse
  • Industrial areas
  • Super Market
  • Assembly shop floor

  • Mounting with hook, chain or Cable
  • Power supply should be disconnected before service

Technical & Ordering Information Download Datasheet

Product ID / Ordering Code Product Description Wattage(W) Nominal Voltage(V) Mains Current(A) CCT (K) Lumen (lm)
VL/HBL-002-LED03050 Venus LED High Bay COB 30/CW 30 230 0.135 5000 2700
VL/HBL-002-LED04065 Venus LED High Bay COB 40/CW 40 230 0.180 6500 3600
VL/HBL-002-LED05050 Venus LED High Bay COB 50/CW 50 230 0.225 5000 4500
VL/HBL-002-LED06065 Venus LED High Bay COB 60/CW 60 230 0.274 6500 5400
VL/HBL-002-LED08065 Venus LED High Bay COB 80/CW 80 230 0.365 6500 7200
VL/HBL-002-LED10050 Venus LED High Bay COB 100/CW 100 230 0.455 5000 9000
VL/HBL-002-LED12050 Venus LED High Bay COB 120/CW 120 230 0.540 5000 10800
VL/HBL-002-LED15050 Venus LED High Bay COB 150/CW 150 230 0.680 5000 13500
VL/HBL-410-LED20057** Venus HVAC LED High Bay 200/CW 200 230 0.915 5700 18000

LED Highbay Light
